UCG-Ultra

Name: UCG-Ultra
Brand: Ubiquiti
SKU: UCGULTRACA
Price: 162.99 CAD
Availability: OutOfStock

$162.99

Cloud Gateway Ultra

Powerful and compact multiWAN UniFi Cloud Gateway with a full suite of advanced routing and security features.

1 $162.99/ea

2-4 $162.48/ea

5-9 $161.97/ea

10-19 $160.96/ea

20+ $159.94/ea

Cloud Gateway Ultra

Fabricant	Ubiquiti
Modèle	UCG-Ultra
UPC	810084695135
Catégorie	Networking Wireless Dual Band — APs & Bridges
Poids	1.85 lbs
Dimensions (boîte)	6.3" × 6.8" × 3.1" (L×P×H)

TechnicalIn The BoxDocumentsFAQ

Overview

Dimensions	141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Network	✓
Managed UniFi Devices	30+
Simultaneous Users Connected	300+
Max. WAN Port Count	4
Default WAN Ports	(1) 2.5 GbE RJ45
1 GbE RJ45	4 (1G/100M/10M)
2.5 GbE RJ45	1 (2.5G/1G/100M/10M)
IDS/IPS Throughput	1 Gbps
Form Factor	Compact desktop
Stateful Firewall	✓
Application-Aware Layer 7 Firewall	✓
DPI & Traffic Identification	✓
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)	✓
Content Filtering	✓
Intrusion Prevention (IPS/IDS)	✓
Ad Blocking	✓
IDS/IPS Signatures	55,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation	✓
License-Free SD-WAN	✓
Site Magic	✓
IPsec	✓
OpenVPN	✓
Identity Endpoint One-Click VPN	✓
Teleport Zero-Configuration VPN	✓
WireGuard	✓
L2TP	✓
Multi-WAN Load Balancing	✓
OSPF	✓
Advanced QoS	✓
Multicast DNS (mDNS)	✓
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)	✓
Integrated RADIUS Server	✓
RADIUS over TLS (RadSec)	✓
Additional Internet Failover with UniFi LTE Backup	✓
Internet Quality and Outage Reporting	✓
MAC Address Table Size	2,000
Policy-based WAN and VPN Routing	✓
Customizable DHCP Server	✓
IPv6 ISP Support	✓
IGMP Proxy	✓
Virtual Network Override	✓
Max. Power Consumption	6.2W
Power Method	USB type C (5V DC/3A)
Power Supply	USB type C (5V DC/3A) (Adapter included)
Supported Voltage Range	100–240V AC
Heat Dissipation	21 BTU/hr
Processor	Quad-core ARM® Cortex®-A53 at 1.5 GHz
System Memory	3 GB
On-board Storage	16 GB
Weight	520 g (1.1 lb)
Enclosure Material	Polycarbonate
LCM Display	0.96" status display
Management	Ethernet Bluetooth
Ethernet	✓
Button	(1) Factory reset
Ambient Operating Temperature	-10 to 40° C (14 to 104° F)
Ambient Operating Humidity	5 to 95% noncondensing
NDAA Compliant	✓
Certifications	CE, FCC, IC, Anatel: 04653-24-08356, SRRC
Application Requirements	UniFi iOS™: Version 10.12.0 and later UniFi Android™: Version 10.11.2 and later
Mobile App	UniFi iOS™: Version 10.12.0 and later UniFi Android™: Version 10.11.2 and later

Specs

Dimensions	141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Network	✓
Managed UniFi Devices	30+
Simultaneous Users Connected	300+
Max. WAN Port Count	4
Default WAN Ports	(1) 2.5 GbE RJ45
1 GbE RJ45	4 (1G/100M/10M)
2.5 GbE RJ45	1 (2.5G/1G/100M/10M)
IDS/IPS Throughput	1 Gbps
Form Factor	Compact desktop
Stateful Firewall	✓
Application-Aware Layer 7 Firewall	✓
DPI & Traffic Identification	✓
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)	✓
Content Filtering	✓
Intrusion Prevention (IPS/IDS)	✓
Ad Blocking	✓
IDS/IPS Signatures	55,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation	✓
License-Free SD-WAN	✓
Site Magic	✓
IPsec	✓
OpenVPN	✓
Identity Endpoint One-Click VPN	✓
Teleport Zero-Configuration VPN	✓
WireGuard	✓
L2TP	✓
Multi-WAN Load Balancing	✓
OSPF	✓
Advanced QoS	✓
Multicast DNS (mDNS)	✓
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)	✓
Integrated RADIUS Server	✓
RADIUS over TLS (RadSec)	✓
Additional Internet Failover with UniFi LTE Backup	✓
Internet Quality and Outage Reporting	✓
MAC Address Table Size	2,000
Policy-based WAN and VPN Routing	✓
Customizable DHCP Server	✓
IPv6 ISP Support	✓
IGMP Proxy	✓
Virtual Network Override	✓
Max. Power Consumption	6.2W
Power Method	USB type C (5V DC/3A)
Power Supply	USB type C (5V DC/3A) (Adapter included)
Supported Voltage Range	100–240V AC
Heat Dissipation	21 BTU/hr
Processor	Quad-core ARM® Cortex®-A53 at 1.5 GHz
System Memory	3 GB
On-board Storage	16 GB
Weight	520 g (1.1 lb)
Enclosure Material	Polycarbonate
LCM Display	0.96" status display
Management	Ethernet Bluetooth
Ethernet	✓
Button	(1) Factory reset
Ambient Operating Temperature	-10 to 40° C (14 to 104° F)
Ambient Operating Humidity	5 to 95% noncondensing
NDAA Compliant	✓
Certifications	CE, FCC, IC, Anatel: 04653-24-08356, SRRC
Mobile App	UniFi iOS™: Version 10.12.0 and later UniFi Android™: Version 10.11.2 and later
