US-48-750W

Name: US-48-750W
Brand: Ubiquiti
SKU: US48750WCA
Price: 1302.99 CAD
Availability: OutOfStock

$1,302.99 $1,415.99

UniFiSwitch 48 Port 750W

Ubiquiti UniFi Switch 48 Port US-48-750W Managed PoE+ Gigabit Switch with SFP 750W. Build and expand your network with the UniFi Switch, part of the Ubiquiti Networks UniFi Enterprise System. The UniFi Switch US-48-750W is a fully managed, high performance PoE+ Gigabit switch with two SFP+ and two SFP ports, providing up to 10 Gbps uplinks and fiber connectivity options for your enterprise networks. The UniFi Switch US-48-750W offers 48 ports of auto-sensing IEEE 802.3af/at or configurable 24V PoE to simplify your infrastructure, and with a total power of 750W, you have the flexibility to power more devices on your network. Managed and configured by the UniFi Controller, the UniFi Switch offers an extensive suite of advanced Layer-2 switching features and protocols, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Controller UI allows admins to configure and monitor virtually all of the switch features in a graphical user interface.

1 $1,302.99/ea

2-4 $1,296.38/ea

5-9 $1,289.77/ea

10-19 $1,283.16/ea

20+ $1,276.56/ea

UniFiSwitch 48 Port 750W

Fabricant	Ubiquiti
Modèle	US-48-750W
UPC	810354020797
Catégorie	Networking — Switches Over 24 Ports
Poids	17.8 lbs
Dimensions (boîte)	16.6" × 22.5" × 3.8" (L×P×H)

TechnicalIn The BoxFAQ

Overview

Dimensions	485 x 374.6 x 43.7 mm (9.09 × 14.75 × 1.72'')
1 GbE RJ45	48 (All PoE+) (1G/100M/10M)
1G SFP	2 (1G)
10G SFP+	2 (10G/1G)
Max. PoE Output	Up to PoE+
Total PoE Availability	750W
Access Lists	128
IPv4	128
MAC	128
LACP Port Aggregation	✓
STP & RSTP	✓
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)	✓
IGMP Snooping	✓
802.1X Control	✓
MAC-Based ACLs & Device Isolation	✓
DHCP Snooping & Guarding	✓
Egress Rate Limit	✓
Flow Control	✓
Storm Control	✓
Multicast & Broadcast Rate Limiting	✓
MAC Address Blocking	✓
IP-Based ACLs & Network Isolation	✓
MAC-Based Port Restriction	✓
Port Isolation	✓
Port Mirroring	✓
Jumbo Frames	✓
LLDP-MED	✓
Voice VLAN	✓
Loop Protection	✓
Virtual Network Override	✓
Power Method	Universal input, 100–240V AC, 50/60 Hz
Power Input Method	AC input
Power Supply	AC/DC, internal, 750W
Supported Voltage Range	100–240V AC
Mount Material	SGCC steel
Supported Rack Depth	400~1200 mm (15.7-47.2")
NDAA Compliant	✓
Application Requirements	Version 6.3.51 and later
UniFi Network	Version 6.3.51 and later

Specs

Dimensions	485 x 374.6 x 43.7 mm (9.09 × 14.75 × 1.72'')
1 GbE RJ45	48 (All PoE+) (1G/100M/10M)
1G SFP	2 (1G)
10G SFP+	2 (10G/1G)
Max. PoE Output	Up to PoE+
Total PoE Availability	750W
IPv4	128
MAC	128
LACP Port Aggregation	✓
STP & RSTP	✓
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)	✓
IGMP Snooping	✓
802.1X Control	✓
MAC-Based ACLs & Device Isolation	✓
DHCP Snooping & Guarding	✓
Egress Rate Limit	✓
Flow Control	✓
Storm Control	✓
Multicast & Broadcast Rate Limiting	✓
MAC Address Blocking	✓
IP-Based ACLs & Network Isolation	✓
MAC-Based Port Restriction	✓
Port Isolation	✓
Port Mirroring	✓
Jumbo Frames	✓
LLDP-MED	✓
Voice VLAN	✓
Loop Protection	✓
Virtual Network Override	✓
Power Method	Universal input, 100–240V AC, 50/60 Hz
Power Input Method	AC input
Power Supply	AC/DC, internal, 750W
Supported Voltage Range	100–240V AC
Mount Material	SGCC steel
Supported Rack Depth	400~1200 mm (15.7-47.2")
NDAA Compliant	✓
UniFi Network	Version 6.3.51 and later
