USW-Pro-XG-Aggregation

Name: USW-Pro-XG-Aggregation
Brand: Ubiquiti
SKU: USWPROXGAGGCA
Price: 3360.99 CAD
Availability: OutOfStock

$3,360.99 $3,449.99

Pro XG Aggregation

Professionalgrade 32port, Layer 3 Etherlighting switch for highcapacity 25G SFP28 connections.

1 $3,360.99/ea

2-4 $3,360.01/ea

5-9 $3,359.04/ea

10-19 $3,358.06/ea

20+ $3,357.08/ea

Pro XG Aggregation

Fabricant	Ubiquiti
Modèle	USW-Pro-XG-Aggregation
UPC	000000000000
Catégorie	Networking — Switches 4 to 10 Ports
Poids	1 lbs
Dimensions (boîte)	1" × 1" × 1" (L×P×H)

TechnicalIn The BoxDocumentsFAQ

Overview

Dimensions	442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9")
25G SFP28	32 (25G/10G/1G)
Redundancy	DC Power Backup
Layer 3	✓
Form Factor	Rack Mount (1U)
Etherlighting™	✓
Switching Capacity	1.6 Tbps
Total Non-Blocking Throughput	800 Gbps
Forwarding Rate	1.2 Bpps
Supported VLANs	1,000
MAC Address Table Size	32,000
ARP Entries	128,000
IPv4 Routes	256,000
IPv4 Static Routes	512
Packet Buffer Size	8 MB
IPv4	256
MAC	256
DHCP Server (Local Networks)	✓
DHCP Relay	✓
Inter-VLAN Routing (Local Networks)	✓
Static Routing (Local Networks)	✓
LACP Port Aggregation	✓
STP & RSTP	✓
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)	✓
IGMP Snooping	✓
802.1X Control	✓
MAC-Based ACLs & Device Isolation	✓
DHCP Snooping & Guarding	✓
Egress Rate Limit	✓
Flow Control	✓
Storm Control	✓
Multicast & Broadcast Rate Limiting	✓
MAC Address Blocking	✓
IP-Based ACLs & Network Isolation	✓
MAC-Based Port Restriction	✓
Port Isolation	✓
Port Mirroring	✓
Jumbo Frames	✓
LLDP-MED	✓
Voice VLAN	✓
Loop Protection	✓
Virtual Network Override	✓
Max. Power Consumption	200W
Power Method	(1) Universal input, 100–240V AC, 50/60 Hz (1) USP RPS DC input
Power Input Method	AC input
Power Supply	AC/DC, internal, 200W
Supported Voltage Range	100–240V AC
Management	Ethernet AR
Heat Dissipation	457 BTU/hr
Weight	Without mounting bracket: 7.1 kg (15.7 lbs) With mounting bracket:7.2 kg (15.9 lbs)
Enclosure Material	SGCC steel
Mount Material	SGCC steel
Supported Rack Depth	482.6 mm (19") four-post racks Posts depths ranging from 600 to 1,066 mm (23.6-42”)
LCM Display	1.3" touchscreen
ESD Protection	Air: ± 12kV, contact: ± 8kV
Ambient Operating Temperature	-5 to 40° C (23 to 104° F)
Ambient Operating Humidity	10 to 90% noncondensing
SFP28	✓
RPS	✓
NDAA Compliant	✓
Certifications	CE, FCC, IC, Anatel: 05977-25-08356
