EAP653 UR

$159.99

EAP653 UR

En rupture de stock

EAP653 UR

Name: EAP653 UR
Brand: TP-Link
SKU: EAP653URCA
Price: 159.99 CAD
Availability: OutOfStock

$159.99

Montage au plafond AX3000

Point d'accès WiFi 6 bi-bande AX3000 à montage au plafond PORT:1 port RJ45 GigabitVITESSE:574 Mbps à 2,4 GHz + 2402 Mbps à 5 GHzCARACTÉRISTIQUES : PoE 802.3at et adaptateur secteur 12V DC non inclus, 3 antennes internes ?L'une des antennes est une antenne auxiliaire pour la bande de fréquences 5G, ce qui améliore la capacité de couverture?, prise en charge 160 MHz, MUMIMO, itinérance transparente, Band Steering, Beamforming, équilibrage de charge, Airtime Fairness, gestion centralisée par le contrôleur Omada SDN, application Omada

Support de plafond AX3000

Vitesses WiFi 6 ultra-rapides : 2402 Mbps sur 5 GHz + 574 Mbps sur 2,4 GHz† Couverture sans fil à très longue portée grâce à plus d'antennes avec une puissance de transmission plus élevée Prend en charge les technologies WiFi 6, telles que HE160, 1024-QAM, etc.‡ Fonctionnalités avancées : Omada Mesh, itinérance transparente, etc.§ Alimenté par PoE+ : prend en charge à la fois 802.3at PoE et CC (adaptateur non inclus) Conception ultra-mince : Φ6,3 po × 1,3 po, un design élégant apporte plus d'agilité S'intègre à la plateforme Omada SDN pour une gestion centralisée

Fabricant	TP-Link
Modèle	EAP653 UR
UPC	810142820271
Catégorie	Networking Wireless Dual Band — APs & Bridges
Poids	1.65 lbs
Dimensions (boîte)	9.6" × 9" × 2.5" (L×P×H)

Specifications

General

Interface	1× Gigabit PoE+ Port
Button	Reset
Power Supply	• 802.3at PoE• 12V DC / 1.5 A (Power Adapter IS NOT included)• 48V Passive PoE
Max. Power Consumption	• EU: 14.2 W• US: 15.5 W
Dimensions ( W x D x H )	6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
Antenna	Internal Omni• 2.4 GHz: 2× 5 dBi• 5 GHz: 3× 5 dBi
Mounting	• Ceiling /Wall Mounting (Kits included)• Junction Box Mounting
Coverage	185 ㎡ (2000 ft²)***
Concurrent Clients	250+**
Wireless Standards	IEEE 802.11ax/ac/n/g/b/a
Frequency	2.4 GHz and 5 GHz
Signal Rate	• 5 GHz: Up to 2402 Mbps†• 2.4 GHz: Up to 574 Mbps†
Wireless Functions	• 1024-QAM• 4× Longer OFDM Symbol• OFDMA• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)• Enable/Disable Wireless Radio• Automatic Channel Assignment• Transmit Power Control (Adjust Transmit Power on dBm)• QoS(WMM)• MU-MIMO(2G: 22 MU-MIMO DL/UL; 5G:22 MU-MIMO DL/UL) • HE160 (160 MHz Bandwidth)‡• Seamless Roaming(802.11k/v/r)§• Omada Mesh§• Band Steering• Load Balance• Airtime Fairness • Beamforming• Rate Limit• Reboot Schedule• Wireless Schedule• Wireless Statistics based on SSID/AP/Client
Wireless Security	• Captive Portal Authentication§• Access Control• Wireless Mac Address Filtering• Wireless Isolation Between Clients• SSID to VLAN Mapping• Rogue AP Detection• 802.1X Support• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power	• CE:<20 dBm(2.4 GHz, EIRP)<23 dBm(5 GHz, Band1 & Band2, EIRP)<29 dBm(5 GHz, Band3, EIRP)• FCC:<26 dBm (2.4 GHz)<27 dBm (5 GHz)
Omada App	Yes
Centralized Management	• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller
Cloud Access	Yes. Require the use of an Omada controller.
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1, v2c, v3
System Logging Local/Remote Syslog	Local/Remote Syslog
SSH	Yes
Web-based Management	HTTP/HTTPS
L3 Management	Yes
Multi-site Management	Yes
Management VLAN	Yes
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller.
Certification	CE, FCC, RoHS
Package Content	• EAP653 UR• Ceiling/Wall Mounting Kit• Installation GuideNote: DC adapter is not included in the package, and is sold separately.
System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉)• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing

TechnicalIn The BoxFAQ

General

Interface	1× Gigabit PoE+ Port
Button	Reset
Power Supply	• 802.3at PoE• 12V DC / 1.5 A (Power Adapter IS NOT included)• 48V Passive PoE
Max. Power Consumption	• EU: 14.2 W• US: 15.5 W
Dimensions ( W x D x H )	6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
Antenna	Internal Omni• 2.4 GHz: 2× 5 dBi• 5 GHz: 3× 5 dBi
Mounting	• Ceiling /Wall Mounting (Kits included)• Junction Box Mounting
Coverage	185 ㎡ (2000 ft²)***
Concurrent Clients	250+**
Wireless Standards	IEEE 802.11ax/ac/n/g/b/a
Frequency	2.4 GHz and 5 GHz
Signal Rate	• 5 GHz: Up to 2402 Mbps†• 2.4 GHz: Up to 574 Mbps†
Wireless Functions	• 1024-QAM• 4× Longer OFDM Symbol• OFDMA• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)• Enable/Disable Wireless Radio• Automatic Channel Assignment• Transmit Power Control (Adjust Transmit Power on dBm)• QoS(WMM)• MU-MIMO(2G: 22 MU-MIMO DL/UL; 5G:22 MU-MIMO DL/UL) • HE160 (160 MHz Bandwidth)‡• Seamless Roaming(802.11k/v/r)§• Omada Mesh§• Band Steering• Load Balance• Airtime Fairness • Beamforming• Rate Limit• Reboot Schedule• Wireless Schedule• Wireless Statistics based on SSID/AP/Client
Wireless Security	• Captive Portal Authentication§• Access Control• Wireless Mac Address Filtering• Wireless Isolation Between Clients• SSID to VLAN Mapping• Rogue AP Detection• 802.1X Support• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power	• CE:<20 dBm(2.4 GHz, EIRP)<23 dBm(5 GHz, Band1 & Band2, EIRP)<29 dBm(5 GHz, Band3, EIRP)• FCC:<26 dBm (2.4 GHz)<27 dBm (5 GHz)
Omada App	Yes
Centralized Management	• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller
Cloud Access	Yes. Require the use of an Omada controller.
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1, v2c, v3
System Logging Local/Remote Syslog	Local/Remote Syslog
SSH	Yes
Web-based Management	HTTP/HTTPS
L3 Management	Yes
Multi-site Management	Yes
Management VLAN	Yes
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller.
Certification	CE, FCC, RoHS
Package Content	• EAP653 UR• Ceiling/Wall Mounting Kit• Installation GuideNote: DC adapter is not included in the package, and is sold separately.
System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉)• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing
